18650 Cylinder Battery Semi-Auto Winding Machine
PRODUCT PARAMETERS
Description
18650 Cylinder Battery Semi-Auto Winding Machine – Precision Lithium Ion Battery Winder
This 18650 Cylinder Battery Semi-Auto Winding Machine is specifically designed for precision winding of 18650 lithium-ion battery cells. It combines manual electrode feeding with automated tape application and cell ejection, making it ideal for research and development, pilot production, and small-batch manufacturing.
Working Process:
- The operator manually introduces the positive and negative electrode plates into the winding section.
- Electrodes are stacked together with the separator material.
- The machine winds the stack according to programmed process requirements.
- Termination tape is automatically applied to secure the wound core.
- The finished battery core is automatically discharged for collection.
Key Features:
- High Precision Winding: Alignment error between diaphragm, anode, and cathode sheets maintained at < ±0.5mm.
- Flexible Material Compatibility: Accommodates electrode widths 8-38mm, lengths 60-300mm, and diaphragm widths 10-40mm.
- Adjustable Needle Width: Rolling needle combination adjustable from 6-15mm for different cell configurations.
- Automatic Tape Application: Termination tape automatically applied at end of winding cycle.
- Auto Discharge: Finished cells automatically ejected for efficient workflow.
- Production Capacity: 6 to 10 PPM (dependent on pole piece length and manual feeding speed).
- Low Drum Shell Rate: <2% for cell thickness ≤6mm, <3% for cell thickness >6mm.
- Compact & Efficient: 1KW power consumption, single-phase 220V operation.
Material Quality Requirements:
- Pole piece width error < 0.1mm
- “S” bending error < 0.5mm/1000mm (no edge warping)
- Diaphragm roll tower shape error < ±0.2mm (no edge warping)
Applications:
- 18650 cylindrical lithium-ion battery production
- Battery R&D laboratories
- Small to medium-scale battery manufacturing
- Prototype cell development
Technical Specifications
| Parameter | Specification |
|---|---|
| Rolling Needle Combination Width | 6 – 15 mm |
| Diaphragm Width | 10 – 40 mm |
| Electrode Width | 8 – 38 mm |
| Electrode Length | 60 – 300 mm |
| Termination Tape Width | 8 – 15 mm |
| Winding Accuracy | Alignment error < ±0.5 mm (diaphragm/anode/cathode) |
| Equipment Capacity | 6 – 10 PPM (varies with electrode length and feeding speed) |
| Drum Shell Rate | <2% (cell thickness ≤6mm) / <3% (cell thickness >6mm) |
| Power Supply | 220 VAC ±5%, single-phase, 1 KW |
| Operation | Manual electrode feeding, automatic tape and discharge |
Material Requirements:
| Parameter | Specification |
|---|---|
| Pole Piece Width Error | < 0.1 mm |
| “S” Bending Error | < 0.5 mm / 1000 mm |
| Edge Condition | No edge warping |
| Diaphragm Roll Tower Error | < ±0.2 mm |
