Industrial Dehumidifier for Lithium Battery Production Lines
PRODUCT PARAMETERS
Description
Industrial Dehumidifier for Lithium Battery Production | 240L/Day | GN-DH8240C | CE Certified
Product Overview
The GN-DH8240C Industrial Dehumidifier is a high-capacity, precision-engineered dehumidification system designed specifically for lithium-ion battery production environments. We developed this robust industrial dehumidifier to maintain the critical low-humidity conditions required for polymer pouch cell assembly and other moisture-sensitive battery manufacturing processes.
This advanced industrial dehumidifier operates on a frozen wetting principle – a fan draws in moist air, which passes through a freezing evaporator where moisture condenses into water. The collected water is either gathered into a container or continuously drained via pipe connection. Dry air is then exhausted through the outlet, gradually reducing ambient humidity to the desired level.
With a powerful 240L/Day dehumidification capacity (at 30℃/80% RH) and coverage area of 190-300 square meters (with 2.6m ceiling height), this industrial dehumidifier delivers the performance needed for battery production facilities. The unit features digital humidity control for real-time monitoring and adjustment, ensuring consistent environmental conditions for quality manufacturing.
Business & Logistics Information
| Parameter | Details |
|---|---|
| Place of Origin | China |
| Brand Name | Gelon |
| Model Number | GN-DH8240C |
| Certification | CE |
| Minimum Order Quantity | 1 pc |
| Packaging Details | Standard exported package: Internal anti-collision protection, external export wooden box packaging |
| Delivery Time | 15 days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 500 pcs per month |
| Warranty | 1 Year |
| After-sales Service | Video Technical Support |
Why Humidity Control is Critical for Lithium Battery Production
Lithium battery manufacturing requires extremely controlled environmental conditions. Moisture is one of the most significant threats to battery quality and safety . When moisture interacts with the electrolyte (specifically LiPF₆), it generates hydrofluoric acid (HF), which can cause :
- Battery swelling and bulging
- SEI film defects that compromise performance
- Reduced battery lifespan and capacity degradation
- Safety hazards including potential explosion in extreme cases
For polymer pouch cell assembly, maintaining proper humidity levels is essential throughout the production process. Critical operations such as electrolyte filling and cell sealing require dew points as low as -40°C or below . Our industrial dehumidifier helps you achieve and maintain these demanding environmental conditions.
Key Design Features
1. High-Capacity Dehumidification
We engineered this industrial dehumidifier to deliver exceptional moisture removal:
- Nominal capacity: 240L/Day at 30℃/80% RH
- Coverage area: 190-300 square meters (2.6m ceiling height)
- Suitable for production halls, dry rooms, and assembly areas
2. Efficient Refrigeration System
The unit utilizes R22 refrigerant in a closed-loop system:
- Freezing evaporator condenses moisture from incoming air
- Efficient heat exchange maximizes dehumidification performance
- Reliable operation in continuous industrial use
3. Digital Humidity Control
The intelligent control system features:
- Real-time humidity monitoring with digital display
- Random freely humidity control – set and maintain your target level
- Automatic adjustment to maintain consistent conditions
4. Robust Construction
We designed this industrial dehumidifier for demanding industrial environments:
- Plastic steel design – beautiful, easy to clean, and practical
- Corrosion-resistant materials suitable for battery production facilities
- Durable components rated for continuous operation
5. Flexible Installation
The unit offers versatile installation options:
- External drainage – continuous drainage via pipe connection
- Universal wheels – can be moved freely throughout your facility
- Left blow type outlet with positive air intake design
6. Automatic Defrost Protection
When ambient temperature drops below 18℃, the system automatically initiates defrosting to prevent ice buildup and maintain performance.
7. Comprehensive Protection Features
- Three-minute time delay for compressor protection
- Rotary protection for reliable operation
- Suitable for continuous industrial use
Technical Specifications
| Parameter | Value | Remarks |
|---|---|---|
| Product Name | Industrial Dehumidifiers System | |
| Application | Lithium Ion Battery Production Line | |
| Usage | Dehumidify | |
| Voltage/Frequency | ~380V / 50Hz | Three-phase industrial power |
| Input Power | 5500W / 11A | |
| Refrigerating Fluid | R22 | Standard refrigerant |
| Nominal Capacity | 240L/Day | At 30℃, 80% RH |
| Dehumidification Area | 190-300 m² | With 2.6m ceiling height |
| Drainage Way | External drainage | Tube continuous drainage |
| Scope of Application | Rotary, under-voltage three minutes time delay | |
| Core Components | Engine, Gear, Pump | |
| Control System | Humidity digital automatic control | Real-time, random freely humidity control |
| Special Feature | Automatic defrost | Below 18℃ ambient |
| Airflow Design | Left blow type outlet | Positive into the wind |
| Mobility | Universal wheels | Free movement |
| Warranty | 1 Year |
How the Industrial Dehumidifier Works
Step 1: Air Intake
The powerful fan draws moist air from your production environment into the industrial dehumidifier. The positive air intake design ensures efficient air circulation throughout the space.
Step 2: Cooling and Condensation
The incoming air passes through the freezing evaporator . As the air cools below its dew point, moisture condenses into water droplets. This is the same principle used in冷冻式除湿机 (condensation dehumidifiers) .
Step 3: Water Collection and Drainage
The condensed water collects in the unit and is either:
- Gathered into an internal container (for periodic manual emptying)
- Continuously drained via pipe connection (for permanent installation)
Step 4: Dry Air Exhaust
The now-dry air is exhausted through the left blow type outlet, gradually reducing the humidity in your production area. The digital controller monitors conditions and adjusts operation to maintain your target humidity level.
Step 5: Automatic Defrost Protection
If ambient temperature falls below 18℃, the system automatically initiates defrosting to prevent ice formation on the evaporator coils, ensuring consistent performance year-round.
Applications
- Lithium Battery Production Lines: Maintaining low humidity for critical processes
- Polymer Pouch Cell Assembly: Protecting moisture-sensitive components
- Electrode Manufacturing: Controlling humidity during coating and drying
- Electrolyte Filling Areas: Preventing moisture contamination during filling
- Cell Sealing Operations: Ensuring proper seal integrity
- Dry Rooms: Supporting controlled environment facilities
Why Choose Gelon GN-DH8240C Industrial Dehumidifier
- High Capacity for Production Environments: With 240L/Day dehumidification capacity covering up to 300m², this industrial dehumidifier delivers the performance needed for real production facilities – not just small labs.
- Digital Precision Control: The real-time digital humidity control lets you set and maintain exact environmental conditions, critical for consistent battery quality.
- Industrial-Grade Reliability: Built with robust components including quality engine, gear, and pump, this unit is designed for continuous operation in demanding industrial settings.
- Flexible Deployment: The universal wheels allow you to move the unit wherever it’s needed, while external drainage enables permanent installation.
- Automatic Protection Features: With under-voltage time delay, rotary protection, and automatic defrost, the system protects itself while maintaining performance.
- Energy-Efficient Operation: The 5500W power input delivers exceptional moisture removal per kilowatt, helping control operating costs.
- CE Certified: We certified this equipment for international markets, meeting stringent safety and quality standards.
- Fast Delivery: With 15 days delivery time and 500 units/month supply capacity, we ensure rapid deployment for your production needs.
Complete Battery Solutions from Gelon
The GN-DH8240C Industrial Dehumidifier is part of Gelon’s comprehensive lithium battery equipment line. We offer a complete ecosystem for battery production:
1. Full Set of Lithium Battery Materials
- Cathode Materials: LiMn₂O₄, LTO, LiNiMnCoO₂ (NMC), LiCoO₂
- Anode Materials: Graphite (MCMB), natural graphite
- Current Collectors: Aluminum foil, copper foil
- Separators: Battery separator
- Aluminum Laminated Film: For pouch cell cases
- Electrolyte: Various formulations
2. Full Set of Lithium Battery Production Equipment
Complete production equipment including:
- Mixing machine → Coating machine → Oven → Rolling machine
- Slitting machine → Stacking machine → Winding machine → Sealing machine
- Industrial dehumidifiers → Glove boxes → And more…
3. Full Set of Lithium Battery Technology
- Laboratory Design: We can design your battery lab according to your requirements
- Production Line Design: Complete production line layout and configuration
- Process Support: Technical guidance for battery manufacturing
Frequently Asked Questions (FAQ)
Q: What is the dehumidification capacity of this industrial dehumidifier?
A: The GN-DH8240C delivers 240L/Day at standard conditions of 30℃ and 80% relative humidity.
Q: What area can this unit cover?
A: With a 2.6m ceiling height, it effectively covers 190-300 square meters of production space.
Q: What type of dehumidification technology does it use?
A: It uses 冷冻式除湿 (condensation dehumidification) technology, where moist air passes through a freezing evaporator to condense water .
Q: What power supply is required?
A: The unit requires ~380V/50Hz three-phase industrial power with 5500W input power (11A).
Q: What refrigerant does it use?
A: It uses R22 refrigerant in a sealed system.
Q: How is the water drained?
A: The unit supports continuous external drainage via tube connection, allowing permanent installation without manual water removal.
Q: Can I move it around my facility?
A: Yes. The unit is equipped with universal wheels for free movement throughout your production area.
Q: How is humidity controlled?
A: The digital humidity automatic control provides real-time monitoring and adjustment. You can set and maintain your target humidity level randomly and freely.
Q: What happens if the temperature drops too low?
A: When ambient temperature falls below 18℃, the system automatically initiates defrosting to prevent ice buildup and maintain performance.
Q: What protection features does it include?
A: The unit features rotary protection and under-voltage three-minute time delay to protect the compressor and ensure reliable operation.
Q: Is the machine CE certified?
A: Yes, this equipment is CE certified, meeting international safety and quality standards.
Q: What is the delivery time?
A: Standard delivery is 15 days after order confirmation.
Q: Do you offer after-sales support?
A: Yes. We provide video technical support and comprehensive after-sales service.
Shipping and Packaging Information
- Packaging: Standard exported package with internal anti-collision protection and external export wooden box packaging ensures safe international delivery
- Shipping Methods: We offer various shipping options based on your location and timeline
