Laboratory Desktop Top Heating Coater
PRODUCT PARAMETERS
Description
Laboratory Desktop Top Heating Coater – Vacuum Coater with Micrometer Applicator for Battery Films
This Laboratory Desktop Top Heating Coater is a precision instrument designed for advanced thin film coating research and development. It is widely used for preparing ceramic thin films, battery material coatings, special nano films, and other high-performance thin film materials. The integrated top heating system enables temperature-controlled coating processes, adapting to future high-temperature film formation requirements.
Key Components & Features:
- Micrometer-Adjustable Applicator: Precision coating thickness control with 0.01mm accuracy; adjustable range 0.01–3.5mm, suitable for coatings thinner than 10 microns.
- Vacuum Aluminum Plate: 250mm(L) × 150mm(W) effective size for quick placement and secure fixation of substrates during coating (custom sizes available).
- Adjustable Coating Stroke: Stroke can be adjusted via stroke switch for different substrate sizes.
- High-Precision Scraper: 150mm standard width scraper ensures uniform coating thickness.
- Built-in Vacuum Pump: Integrated vacuum system achieving vacuum degree ≥-84KPa for immediate substrate adsorption.
- Top Heating System: Adjustable heating up to 100°C (recommended operating temperature around 80°C).
- Optional Viscosity Meter: Can be equipped to monitor and maintain optimal slurry viscosity for consistent coating quality.
Typical Applications:
- Lithium battery electrode coatings
- Ceramic thin film research
- Nano material film preparation
- Advanced material R&D requiring precise coating thickness
Recommended Supporting Equipment:
- Vacuum oven for film drying and binder removal
- Calendering equipment for electrode densification and substrate adhesion
Technical Parameters
| Parameter | Specification | Note |
|---|---|---|
| Vacuum Degree | ≥ -84 KPa | Integrated vacuum pump |
| Heating Temperature | Suggested ~80°C | MAX: 100°C |
| Vacuum Suction Plate Effective Size | 250mm(L) × 150mm(W) | Other sizes customizable |
| Scraper Width | 150mm (standard) | Adjustable thickness: 0.01–3.5mm |
| Coating Thickness Precision | 0.01 mm | Suitable for <10μm coatings |
| Power Supply | AC220V/50Hz or AC110V/60Hz | Customizable |
| Power Consumption | 1800 W | Requires <4Ω grounding |
| Equipment Dimensions | Approx. L550 × W396 × H370 mm | – |
| Equipment Weight | Approx. 55 kg | – |
| Optional Accessory | Viscosity meter | For slurry viscosity control |
