Microporous Aluminum Foil
PRODUCT PARAMETERS
Description
Microporous Aluminum Foil – High-Performance Perforated Current Collector for Li-Ion Batteries
Microporous aluminum foil is a new type of current collector manufactured through secondary processing of conventional lithium battery aluminum foil. Using precision mechanical processing to create uniform micro-holes, this innovative material maximizes the retention of the original foil’s physical and chemical properties while adding the benefits of a porous structure.
Key Advantages:
- Enhanced Electrolyte Wetting: Microporous structure improves electrolyte penetration and ion transport.
- Reduced Weight: Perforations decrease overall mass without compromising mechanical integrity.
- Improved Electrode Adhesion: Pores provide mechanical interlocking sites for active materials.
- Maintained Material Properties: Secondary processing preserves the excellent conductivity and strength of aluminum.
- Customizable Designs: Various hole densities and retention patterns available for specific applications.
Applications:
- Lithium-ion battery cathodes
- Supercapacitor electrodes
- Lithium-ion capacitors
- Advanced energy storage research
- High-rate battery applications
Technical Specifications – Microporous Aluminum Foil
| Item | Unit | Specification |
|---|---|---|
| Series | % | H18, H16 |
| Thickness | mm | 0.010 – 0.025 |
| Surface Density | g/m² | Customizable |
| Width | mm | 0 – 1000 |
| Hole Density | PCS/cm² | 200 – 800 |
| PCS/cm² | 800 – 1500 | |
| PCS/cm² | 1500 – 2000 | |
| PCS/cm² | 2000 – 3000 | |
| Hole Consistency | % | 80 – 90 |
| Tensile Strength | MPa | 100 – 260 |
| Elongation Rate | % | 0.5 – 2.42 |
| Specific Resistance | μΩ·cm | GB/T228.1-2010 |
| Wettability (Dyne Value) | dyne | 40 |
Structure Modes
1. Full Surface Microporous Foil
- Micro holes across entire width
- No solid side walls
- Maximum porosity and weight reduction
2. Retaining (Ribbed) Microporous Foil
Designed with solid areas (ribs) for enhanced mechanical strength and current collection. Available configurations:
- Both sides blocked
- Both sides + middle ribs
- Multi-wide ribs
Technical Requirement for Ribs:
In ribbed series products, the micro hole density within the rib areas shall be less than 10% of the effective hole density.
