PVDF Binder for Lithium Ion Battery – Battery Grade Polyvinylidene Fluoride Powder
PRODUCT PARAMETERS
Description
Gelon GN-PVDF-5130 is a battery grade PVDF binder for lithium ion battery electrode preparation. This polyvinylidene fluoride powder is designed to be mixed with cathode powder to prepare lithium-ion battery electrodes. It is vacuum sealed in a plastic bag and packed in a wooden case for safe export delivery.
As a PVDF binder supplier from China, Gelon provides stable supply, CE certification, flexible MOQ, and fast delivery for battery manufacturers, research labs, and battery material distributors.
MOQ: 1 kg
Supply Ability: 10,000 kg/month
Delivery Time: 5–12 days
Battery Grade PVDF Binder for Lithium Ion Battery
PVDF, or polyvinylidene fluoride, is widely used as a binder in lithium-ion battery cathode production. It helps bind active materials, conductive additives, and current collectors into a stable electrode structure.
Gelon GN-PVDF-5130 is supplied as a white powder and is suitable for lithium battery electrode slurry preparation. It can be processed with cathode materials and suitable solvents to form a uniform electrode coating.
Typical Applications
- Lithium-ion battery cathode electrode
- Li-ion battery positive electrode slurry
- Battery research and pilot production
- Industrial lithium battery manufacturing
- Electrode material mixing and coating
Key Features of Gelon GN-PVDF-5130
- Battery grade PVDF binder for lithium-ion battery electrodes
- White powder form for electrode slurry preparation
- Good chemical stability
- High heat stability: >375°C
- Melting temperature: 160–168°C
- CE certified
- Vacuum sealed plastic bag packaging
- Wooden case for export transportation
- MOQ from 1 kg
- Stable monthly supply: 10,000 kg/month
Technical Specifications
| Item | Typical Data |
|---|---|
| Product Name | PVDF 5130 |
| Model Number | GN-PVDF-5130 |
| Brand Name | Gelon |
| Appearance | White Powder |
| Density | 1.75–1.78 g/cm³ |
| Water Absorption (23°C, 24 hr) | <0.20% |
| Tensile Modulus (23°C) | 1000–1500 MPa |
| Glass Transition Temperature | -40.0°C |
| Melting Temperature | 160–168°C |
| Heat Stability | >375°C |
| Heat of Fusion | 40.0–48.0 J/g |
| Peak Crystallization Temperature (DSC) | 135–140°C |
| Certification | CE |
| Place of Origin | China |
| MOQ | 1 kg |
| Packaging | Vacuum sealed plastic bag + wooden case |
| Delivery Time | 5–12 days |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 10,000 kg/month |
Note: The data above is typical data for PVDF 5130. For PVDF 6020 and PVDF 900, please contact Gelon for the latest datasheet and selection advice.
Available PVDF Models: 5130, 6020, 900
Gelon can supply battery grade PVDF binder materials for lithium-ion battery applications, including:
- PVDF 5130
- PVDF 6020
- PVDF 900
The GN-PVDF-5130 is one of our main PVDF binder models for lithium battery cathode electrode preparation. If you need PVDF 6020 or PVDF 900, please send us your required specification, application, and annual demand. Our team will recommend the suitable grade and provide a quotation.
Packaging, MOQ, and Delivery
| Item | Details |
|---|---|
| Minimum Order Quantity | 1 kg |
| Packaging | Vacuum sealed plastic bag, then wooden case |
| Delivery Time | 5–12 days |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 10,000 kg/month |
| Port | China main port |
| Customization | Available upon request |
The product is vacuum sealed to reduce moisture exposure during storage and transportation. Wooden case packaging is used for export safety.
Why Choose Gelon as Your PVDF Binder Supplier?
Gelon is a China-based supplier supporting lithium battery equipment and materials. We help battery manufacturers, research institutions, and material distributors source reliable battery materials.
Our Advantages
- Battery grade PVDF binder for lithium-ion battery
- CE certified
- Stable supply capacity: 10,000 kg/month
- Flexible MOQ: from 1 kg
- Fast delivery: 5–12 days
- Export-standard packaging
- Professional support for model selection
- Suitable for both research and production use
Whether you are looking for PVDF binder for lithium battery cathode, polyvinylidene fluoride powder, or battery grade PVDF binder, Gelon can support your project with reliable products and responsive service.
FAQ
Q1: What is PVDF binder used for in lithium-ion batteries?
PVDF binder is used to bind cathode active materials, conductive additives, and current collectors together. It helps form a stable electrode coating during lithium-ion battery production.
Q2: Is Gelon GN-PVDF-5130 battery grade?
Yes. Gelon GN-PVDF-5130 is supplied as a battery grade PVDF binder for lithium-ion battery electrode preparation.
Q3: What PVDF models are available?
We can supply PVDF 5130, PVDF 6020, and PVDF 900. Please contact us for the specific datasheet and selection recommendation.
Q4: What is the MOQ?
The minimum order quantity is 1 kg.
Q5: How is the PVDF binder packaged?
It is vacuum sealed in a plastic bag and packed in a wooden case for export delivery.
Q6: What is the delivery time?
The typical delivery time is 5–12 days.
Q7: What payment terms do you accept?
We accept L/C, T/T, and Western Union.
Q8: Can I get a sample or datasheet?
Please contact us to discuss sample availability, datasheet, COA, and other technical documents.
Request a Quote for PVDF Binder for Lithium Ion Battery
Need PVDF 5130, PVDF 6020, or PVDF 900 for your lithium battery project?
Contact Gelon today for:
- Product quotation
- Datasheet and technical support
- Model selection advice
- Sample availability
- Bulk supply planning
Request a Quote / Contact Gelon
