5L Double Planetary Dispersing Mixer
PRODUCT PARAMETERS
Description
5L Double Planetary Dispersing Mixer GN-PM-5L – High-Shear Vacuum Mixer for Battery Slurries
The GN-PM-5L Double Planetary Dispersing Mixer is a high-performance mixing system designed for preparation of advanced battery slurries and other high-viscosity materials. It combines planetary stirring with high-speed dispersion in a single unit, ensuring excellent dispersion and uniformity for demanding applications.
Main Features:
- No-Scrape Design: Eliminates material buildup on vessel walls for complete mixing and easy cleaning.
- High Rigidity Construction: Robust mechanical design ensures stable operation under high torque conditions.
- Dynamic Temperature Measurement: Real-time monitoring of material temperature during mixing.
- Variable Cross-Section Kneading: Optimized blade geometry provides three-dimensional mixing action for thorough homogenization.
- Rapid Dispersion: High-speed dispersion shaft (up to 9200r/min) quickly breaks agglomerates and distributes additives.
Applications:
- LCO (Lithium Cobalt Oxide) battery slurry preparation
- LFP (Lithium Iron Phosphate) cathode slurries
- NCA (Nickel Cobalt Aluminum) electrode formulations
- Fluorescent material dispersion
- Ceramic slurries and advanced material compounding
Technical Parameters – GN-PM Series
| Model | Effective Volume (L) | Design Volume (L) | Stirring Motor (kW) | Dispersed Motor (kW) | Revolution Speed (r/min) | Stirring Speed (r/min) | Dispersion Speed (r/min) |
|---|---|---|---|---|---|---|---|
| GN-PM-1L | 1 | 1.6 | 0.55 | 0.75 | 0–62 | 0–118 | 0–9800 |
| GN-PM-2L | 2 | 3.2 | 0.55 | 0.75 | 0–62 | 0–118 | 0–9800 |
| GN-PM-5L | 5 | 7.8 | 1.1 | 1.5 | 0–62 | 0–100 | 0–9200 |
| GN-PM-10L | 10 | 14 | 1.5 | 2.2 | 0–55 | 0–92 | 0–8000 |
| GN-PM-15L | 15 | 24 | 1.5 | 2.2 | 0–55 | 0–85 | 0–6600 |
| GN-PM-20L | 20 | 29 | 2.2 | 3 | 0–55 | 0–80 | 0–6000 |
| GN-PM-30L | 30 | 44 | 3 | 3.7 | 0–50 | 0–75 | 0–5200 |
| GN-PM-40L | 40 | 56 | 3 | 3.7 | 0–45 | 0–70 | 0–4800 |
Note: Revolution speed refers to the orbital motion of the stirring assembly; stirring speed is the rotational speed of the planetary blades; dispersion speed is the rotational speed of the high-speed disperser shaft.
