Single Station Glove Box
PRODUCT PARAMETERS
Description
Single Station Glove Box – Integrated Gas Purifier, <1ppm H₂O/O₂, Siemens PLC
We engineered this Single Station Glove Box as a complete inert atmosphere workstation for advanced materials research and battery development. It integrates a high-performance gas purification system directly into the glove box, continuously removing water and oxygen through recirculation. As a result, it maintains ultra-low impurity levels below 1ppm for both H₂O and O₂.
Key Features:
- Integrated Gas Purifier: The single-column purifier recirculates and cleans the inert gas, so you achieve consistent atmosphere purity without external connections.
- Siemens PLC Control: The programmable logic controller automates purification cycles, thus ensuring reliable long-term operation.
- Ultra-Low Impurities: Water content <1ppm and oxygen content <1ppm, making it suitable for moisture/oxygen-sensitive materials like lithium battery electrodes.
- Robust Construction: Stainless steel build provides durability and easy cleaning.
- Integrated Analyzers: Built-in oxygen analyzer (0–1000ppm) and water analyzer (0–500ppm) for real-time monitoring.
- High Vacuum Capability: Vacuum pump achieves ≤2×10⁻³ Pa, enabling fast chamber evacuation and regeneration.
Applications:
- Lithium-ion battery R&D (electrode preparation, cell assembly)
- Air-sensitive material handling
- Organic and inorganic synthesis
- Semiconductor and nanotechnology research
- Glove box-based manufacturing processes
Technical Specifications
| Parameter | Specification |
|---|---|
| Control System | Siemens PLC |
| Purifier Type | Single column, integrated |
| Water Content | <1 ppm |
| Oxygen Content | <1 ppm |
| Oxygen Analyzer Range | 0 – 1000 ppm |
| Water Analyzer Range | 0 – 500 ppm |
| Power Supply | AC220V / 50Hz |
| Vacuum Pump | Ultimate pressure ≤2×10⁻³ Pa |
| Dimensions (L×W×H) | 1220 × 800 × 1900 mm |
| Weight | 650 kg |
| Material | Stainless steel |
| Operation | Recirculating inert gas with continuous purification |
